Outdoor P8 surface mount three-in-one technical parameters
Module Unit Module	Item  Item	Parameter  Parameter
	Model      Model Number	UN-P8-4S
	Module size      Module size	256mm*128mm
	Physical spacing    Pixel pitch	8mm
	Physical Density      Pixels Density	15625 points / m2
	Emission color to    Pixel configuration	1R1G1B
	LED package      mode	SMD2828
	Modules respectively of     Pixel resolution	32dots(W)*16 dots(H)
	Module Maximum power consumption  Max Power consumpion	25W
	Module weight       Weight	0.35kg
	Drive mode       Drive type	Constant Current Driver Constant drive
	Scan mode       Scan mode	1/4 scan  1 / 4scan
	Interface       Port type	HUB75-A
	White balance brightness     Brightness of white balance	≥ 5500cd/m2
	Packaging carton size   Package of Carton
	Packaging       Quantity
	Carton weight       G.weight
