项目 |
Item |
UN-1.2 |
UN-1.5 |
UN-1.8 |
|
点间距 |
Pixel pitch |
1.25mm |
1.56mm |
1.875mm |
|
模组尺寸 |
Module size |
150*168.75mm |
150*168.75mm |
150*168.75mm |
|
横组分辨率 |
Module resolution |
120x135 |
96x108 |
80x90 |
|
物理密度 |
Physical density |
640000 dots/m2 |
410914 dots/m2 |
284444 dots/m2 |
|
灯珠类型 |
LED type |
SMD1010 |
SMD1212 |
SMD1515 |
|
箱体尺寸 |
Cabinet size |
600*337.5*30mm |
600*337.5*30mm |
600*337.5*30mm |
|
箱体分辨率 |
Cabinet resolution |
480*270 |
384*216 |
320*180 |
|
箱体重H |
Cabinet weight |
3.6kg |
3.6kg |
3.6kg |
|
箱体材质 |
Cabinet material |
Die casting aluminum |
Die casting aluminum |
Die casting aluminum |
|
维护方式 |
Maintenance way |
Front |
Front |
Front |
|
最佳视距 |
Best viewing distance |
|
》1.5m |
Nl.8m |
|
最佳视角 |
Best viewing angle |
H:160°;V:160° |
H:160°;V:160* |
H:160°;V:160° |
|
驱动方式 |
Driving method (Constant Current) |
1/45 Scan |
1/54 Scan |
1/30 Scan, |
|
帧速率 |
Video frame rate |
WOHz |
&60 Hz |
WOHz |
|
刷新率 |
Refresh rate |
1920-3840HZ |
1920-3840Hz |
1920-3840Hz |
|
亮度 |
Brightness |
&650nits |
&650nits |
&650nits |
|
灰度等级 |
Grey Level |
12-16bit |
12-16bit |
12-16bit |
|
防护等级 |
Ingress protection |
Ip43 |
IP43 |
IP43 |
|
平均功離 |
Average power consumption |
295W |
295W |
295W |
|
Life Time |
Life Time |
>100,000 Hours |
>100,000 Hours |
>100,000 Hours |
|
The rate |
The rate |
<0.0002 |
<0.0002 |
<0.0002 |
|
2K/4K/8K/16K |
|
16 bit gray scale |
|
|
68.7 billion colors |
Full front service design
Hard connection design
Ultra Thin (only 30mm thickness)
Ultra HD
16:9 GOLD Ratio
|
30mm |
|
重量仅3.6kg Weight only 3.6kg |
|
产品应用 Product application |
