项目 |
Item |
UN-2 |
UN-2.5 |
|
点间距 |
Pixel pitch |
2mm |
2,5mm |
|
模组尺寸 |
Module size |
320*160mm |
320*160mm |
|
模组分辨率 |
Module resolution |
160x80 |
128*64 |
|
物理密度 |
Physical density |
250000 dots/m2 |
160000 dots/m 2 |
|
灯珠类型 |
LED type |
SMD1515 |
SMD2020 |
|
箱体尺寸 |
Cabinet size |
640*480*59mm |
640*480*59mm |
|
箱体分辨率 |
Cabinet resolution |
320*240 |
256*192 |
|
箱体垣量 |
Cabinet weight |
8kg |
8kg |
|
箱体材质 |
Cabinet material |
Die casting aluminum |
Die casting aluminum |
|
维护方式 |
Maintenance way |
Front |
Front |
|
最佳视距 |
Best view! ng distance |
&2 m |
&2.5m |
|
最佳视角 |
Best view! ng angle |
H:160°;V:160° |
H: 160°;V:160° |
|
驱动方式 |
Driving method (Constant Current) |
1/40 Scan |
1/32 Scan |
|
帧速率 |
Video frame rate |
260 Hz |
&60 Hz |
|
刷新率 |
Refresh rate |
1920-3840Hz |
1920-3840Hz |
|
亮度 |
Brightness |
&800nits |
&800nits |
|
灰度等级 |
Grey Level |
12-16bit |
12-16bit |
|
防护等级 |
Ingress protection |
IP43 |
IP43 |
|
平均功耗 |
Average power consumption |
290W |
290W |
|
Life Time |
Life Time |
>100,000 Hours |
>100,000 Hours |
|
The rate |
The rate |
<0.0002 |
<0.0002 |
|
项目 |
Item |
UN-3.07 |
UN-4 |
|
点间距 |
Pixel pitch |
3.076mm |
4mm |
|
模组尺寸 |
Module size |
320*160mm |
320*160mm |
|
模组分辨率 |
Module resolution |
104x52 |
80x40 |
|
物理密度 |
Physical density |
105688 dots/m2 |
62500 dots/m2 |
|
灯珠类型 |
LED type |
SMD2020 |
SMD2020 |
|
箱体尺寸 |
Cabinet size |
640*480*59mm |
640*480*59mm |
|
箱体分辨率 |
Cabinet resolution |
208*156 |
160*120 |
|
箱体車量 |
Cabinet weight |
8kg |
8kg |
|
箱体材质 |
Cabinet material |
Die casting aluminum |
Die casting aluminum |
|
維护方式 |
Maintenance way |
Front |
Front |
|
最佳视距 |
Best viewing distance |
23m |
a4m |
|
最隹视角 |
Best viewing angle |
H: 160°; V: 160° |
H:160°; V:160° |
|
驱动方式 |
Driving method (Constant Current) |
1/26 Scan, |
1/20 Scan |
|
帧速率 |
Video frame rate |
260 Hz |
£60 Hz |
|
刷新率 |
Refresh rate |
1920-3840HZ |
1920-3840Hz |
|
亮度 |
Brightness |
a800nits |
&800nits |
|
灰度等级 |
Grey Level |
12-16bit |
12-16bit |
|
防护等级 |
Ingress protection |
IP43 |
IP43 |
|
平均功耗 |
Average power consumption |
195W |
195W |
|
Life Time |
Life Time |
>100,000 Hours |
>100,000 Hours |
|
The rate |
The rate |
<0.0002 |
<0.0002 |
